15kWh 48V 300ah LiFePO4 Battery
Are Lithium Iron Phosphate Batteries Safe?The EGbatt 15kWh Lithium Battery is a low-voltage home storage battery with a nominal voltage of 51.2V that stores energy from the PV panel and discharges it when needed. Used in conjunction with a compatible inverter, it allows for energy backup, lower power costs, and enhanced PV self-consumption.
This battery pack has a 200A internal Battery Management System (BMS) that ensures safe and efficient operation. It also has a 99% operating efficiency, providing maximum energy density and flexible racking options. The battery pack is environmentally friendly and lead-free, making it a sustainable choice for energy storage.
The EGbatt Lithium battery is designed for stress-free battery bank expansion capacity and has a longer lifespan of 10-20 years. It comes with a reliable built-in BMS that manages voltage, current, temperature, and health, ensuring optimal performance and safety. EGbatt Lithium battery is a top-of-the-line product that features tier one, A+ cell composition, high efficiency, and a reliable built-in BMS. It is an excellent choice for anyone looking for a long-lasting and efficient energy storage solution.
Features
- Lithium battery LiFePO4 48v 300Ah 15kWh for solar system solutions. Long life guaranteed with deep cycles.
- Battery has built-in BMS that monitors its operation and prevents the battery from operating outside designed limitations.
- Battery can be easily expanded by adding more battery packs in parallel connection.
- 95% DOD , More than 9500 cycle times.
- Convenient CAN&RS485 Communication by easy settings from touch screen.
- Higher energy density with 4 fuma wheels for easy move. either can be fixed on the wall flexible
Intelligent Heating System: Our batteries automatically activate their heating function when temperatures drop below 5°C, ensuring optimal performance even in frigid environments of -20°C.
Plug-and-Play Inverter Compatibility: The PACE Battery Management System (BMS) seamlessly integrates with a wide range of popular inverters, including (but not limited to) Victron, Pylontech, Growatt, Sofar, Solis, and Goodwe. Changing the inverter protocol doesn't involve any complex software downloads, you can change it simply by navigating the LCD Touchscreen.
Unwavering Confidence in Quality: We stand behind the exceptional design and construction of our batteries, offering an industry-leading 10-year warranty and a 15 year shelf-life. This testament to our craftsmanship reflects our commitment to delivering products that last.
Intuitive Touchscreen Interface: The 5-inch TFT LCD touchscreen provides a user-friendly interface for monitoring system status and adjusting inverter protocols.
Energy-Efficient Sleep Mode: When not in use, the touchscreen automatically enters sleep mode, conserving precious energy while ensuring instant access to detailed system information upon activation.
Premium Grade A CATL Cells: The EGbatt Energy 15.5kWh Battery utilizes 16 premium LF304 Grade A EVE cells or CATL brand, renowned for their exceptional lifespan of 9500 cycles at a discharge rate of 200A per cycle.
- Active Balancing: Contains a 2A JK Active Balancer to ensure seamless cell balancing during the charging process.
Datasheet
| TYPE | 48v 300ah lifepo4 home battery bank |
|---|---|
| Model | LFP48300 |
| Battery Capacity [Ah] | 300 Ah |
| Nominal Battery Energy [kwh] | 15 KWH |
| Max Discharge Current [A] | 200 |
| Net Weight | 135 |
| Dimension [H*W*D, mm] | 850(with wheels)*453*240mm34.4(with wheels)*17.7*9.5inch |
| Operating Temperature Range | 0-55 |
| Life Cycles | 9500 |
| Nominal Voltage [V] | 51.2v |
| Communication | CANbus/RS485 |
| Certificate & Safety Standard | CE MSDS UN38.3 |
| Warranty | 10 |
| Alarms | All |
| Pros | Easy installation Scalability |
| Monitoring & Protection | BMS/Monitor |
Scalable Energy Storage: Up to 15 batteries can be connected in parallel to expand energy storage capacity to suit your specific needs.
Enhanced Safety with DC Breaker: Each 15.3kWh battery is equipped with a 250A DC Breaker, safeguarding the system against potential faults by interrupting power flow and shutting off the electrical current in the event of critical issues.
- Wheels for Portability: The fact that the Fogstar Energy 15.3kWh Battery has wheels makes it extremely easy to move around, even with its 140kg weight. This is a significant advantage, especially for homeowners who may need to relocate the battery for maintenance or installation purposes.
- Wall Mounting Brackets: The battery also comes with optional wall mounting brackets, enabling you to free up valuable floor space, making the battery less intrusive and allowing for more flexible room layout. Simply select the wall mount option above to add this to your order.
How long will a 48V 300Ah lithium battery last?
To determine how long a 48V 300Ah lithium battery will last, you'll need to know the load (in watts) you're drawing from it. You can calculate the runtime using the following formula:
Runtime (in hours) = Battery capacity (in watt-hours) / Load (in watts)
For a 48V 300Ah battery, the total capacity is 15000watt-hours (48V x 300Ah). Of cause, EGbatt 48v battery is normally rated 51.2v. So, the total energy will be 51.2V*300 AH=15.36KWH
Simply divide this capacity by your load to find the runtime. What load are you planning to use?
